ULNA3013 NOAA MKIV

Product No.:
10225
Unkown shippingtime (abroad may vary)
from 119,00 EUR

incl. 19% tax excl. Shipping costs

Add to wish list
Price offer
Ask about product
Description
Low Noise NOAA Amplifier
Specification
  • Frequency range 136-146 MHz
  • Nose Figure 0,5 dB
  • Gain 18dB
  • Max. Input level+13 dBm
  • Return loss   S11 13 dB
  • Return loss output S22 20 dB
  • O-IP3 +38 dBm
  • I-IP3m+18 dBm
  • DC supply 8-24V DC@150 mA
  • Dimension 99X55X37 mm
